TS G3 (FULTEC®) Metal Corrugated Gasket

Features:

TS G3 (FULTEC ^® ) metal corrugated gasket consists of a corrugated metal core plate and a non-metallic layer covering its upper and lower surfaces. The non-metallic covering layer is used for sealing, and the metal core plate serves as a reinforcing gasket and positioning function. The patented manufacturing process enables the gasket to have sufficient mechanical strength and good resilience, ensuring excellent sealing performance under low bolt tightening force.

advantage:

◆  The metal inner core with multiple concentric circular corrugations has a labyrinth sealing effect and effectively blocks the leakage of sealing fluid;

◆  Maintain excellent sealing performance under low bolt tightening load;

◆  Good rebound compression performance and chemical corrosion resistance;

◆  Choose flexible graphite covering layer with good fire resistance;

◆  Choose GORE GR® ^expanded  polytetrafluoroethylene covering layer, which has resistance to cold flow creep, low stress relaxation, and achieves effective sealing.

application:

TS G3 (FULTEC ^® ) can be used for a wide range of industrial sealing needs, including gasket sealing of pipelines, valves, containers and equipment in nuclear power, petrochemical, food, pharmaceutical and other industries. It is suitable for high temperature and high pressure, flammable, explosive and toxic media. FULTEC under alternating temperatures and pressures .^® still exhibits good sealing performance

Types, models and applications:

                          Main models of TS G3 (FULTEC®) metal corrugated gasket

Material:
